Friday, June 27, 2014

Basic Operations on Array (Traversal, Insertion, Deletion, Search) - Data Structures - C++ Program (Object Oriented)

Problem Question


Implement the data structure, Array, and write a program to perform basic operations, Traversal, Insertion, Deletion, and Search on it.

Explanation of Problem


In this program, we are required to use array and perform the basic operations, listed above, on it. Since traversal is nothing but going through all the elements, there is no point performing only traversal since there won't be any output of it. So the method, displayArray, which displays the whole array in my program, is to be considered as traversal of the array. Search is implemented as sequential search for simplicity of the program in the method findPosition.

Code


#include <iostream> //Support c++
#include <cstdlib> //For exit()

/**@Title: OOArray.cpp*
*@Programming Paradigm: Object Oriented*
*@Language: C++*
*@Compiler: GNU GCC*
*@IDE: Code::Blocks 13.12*
*@Author: Rogue Coder*
*@URL: http://letsplaycoding.blogspot.com/*
*@Date: 27-06-2014*
*/

class myArray
{
private:
  int arr[1000];

public:
  int arraySize;

  myArray()
  {
    std::cout << "\n\aEnter the size of the array(Upto 1000): ";
    std::cin >> arraySize;
    std::cout << "\n\aFill the array with " << arraySize;
    std::cout << " elements: ";
    int i = 0;
    for ( i = 0; i < arraySize; i++ )
      std::cin >> arr[i];
  }

  myArray(int argArraySize)
  {
    arraySize = argArraySize;
    std::cout << "\n\aFill the array with " << arraySize;
    std::cout << " elements: ";
    int i = 0;
    for ( i = 0; i < arraySize; i++ )
      std::cin >> arr[i];
  }

  void insertIntoArray(int insertAt, int insertMe)
  {
    if ( arraySize < 1000 )
    {
      arraySize++;
      if ( insertAt > arraySize )
      {
        std::cout << "\nThe array as yet has " << arraySize - 1;
        std::cout << " elements.\nThus the new element will be inserted at position " << arraySize;
        std::cout << " in the array.\n";
        insertAt = arraySize;
      }
      int i = 0;
      for ( i = arraySize + 1; i >= insertAt; i-- )
        arr[i] = arr[i - 1];
      arr[insertAt - 1] = insertMe;
    }
    else
      std::cout << "\n\n\aALREADY AT LIMITS\n\n\a";
  }

  void findPosition(int findMe)
  {
    int i = 0, flag = 0;
    for ( i = 0; i < arraySize; i++)
    {
      if ( arr[i] == findMe )
      {
        std::cout << "The number was found at: " << i + 1 << std::endl;
        flag = 1;
      }
    }
    if ( flag != 1 )
      std::cout<<"The number was not found!" << std::endl;
  }

  void deleteFromArray(int deleteMe)
  {
    int i = 0, j = 0, flag = 0;
    for ( i = 0; i < arraySize; i++)
    {
      if ( arr[i] == deleteMe )
      {
        arraySize--;
        for ( j = i; j < arraySize + 1; j++ )
          arr[j] = arr[j + 1];
        flag = 1;
        i = -1;
      }
    }
    if ( flag != 1 )
      std::cout<<"The number was not found!" << std::endl;
  }

  void displayArray()
  {
    int i = 0;
    std::cout << "\n\aCurrently the array is:";
    for (i = 0; i < arraySize; i++)
      std::cout << " " << arr[i];
  }
};

int main()
{
  std::cout << "\n\aWelcome to ArrayOps v2.0\n\aMade by Rogue Coder\n";
  myArray arrayObject;
  int choice = 0, num, pos;
  do
  {
    arrayObject.displayArray();
    std::cout << "\a\nChoices:\n1. Insert\n2. Delete\n3. Find\n4. Exit\nYour Choice: ";
    std::cin >> choice;
    switch (choice)
    {
    case 1:
      std::cout << "\nEnter the number to be inserted: ";
      std::cin >> num;
      std::cout << "\nEnter the position where to enter: ";
      std::cin >> pos;
      arrayObject.insertIntoArray(pos, num);
      break;
    case 2:
      std::cout << "\nEnter the number to be deleted: ";
      std::cin >> num;
      arrayObject.deleteFromArray(num);
      break;
    case 3:
      std::cout << "\nEnter the number to be found: ";
      std::cin >> num;
      arrayObject.findPosition(num);
      break;
    case 4:
      std::cout << "\n\n\aThank You for Using ArrayOps v2.0\n\aMade by Rogue Coder\n\aPress any key to exit.";
      std::cin.get();
      exit(0);
      break;
    default:
      std::cout << "\a\n\nWRONG CHOICE\a\n\n";
      break;
    }
  }
  while ( choice != 4 );
  return 0;
}


Explanation of Code


#include <iostream> -> The compiler calls the Preprocessor to include the IOSTREAM(Standard Input / Output Streams Library) header file into the program, thus letting the use of the Standard Input / Output Streams functions like std::cin and std::cout. As per C++11 specification, including <iostream> automatically includes also <ios>, <streambuf>, <istream>, <ostream> and <iosfwd>.

int main() -> The entry point of the program where the execution starts. This function has to be named main. As per the ANSI specification, the return type has to be int. Since the return type is specified as int in my program, I have to use a return statement at the end of my code. So I use return 0 since zero returned from a function, by convention, implies a correct execution of the program. The return values are used to debug the program.

std::cin (extern istream cin) -> Standard Input Stream, and object of class istream. It is generally used with the extraction operator (>>), though we can use member functions like get (cin.get()), read (cin.read()), etc. for the input. The use of extraction operator is much more popular due to the fact that it aids in getting formatted input.

std::cout (extern ostream cout) -> Standard Output Stream, and object of class ostream. It is generally used with the insertion operator (<<), though we can use member functions like write (cout.write()) for the output. The use of insertions operator is much more popular due to the fact that it aids in giving formatted output.

std::endl (ostream& endl (ostream& os)) -> This is a function which is used to insert a newline character and flush the stream. Because this function is a manipulator, it is designed to be used alone with no arguments in conjunction with the insertion (<<) operations on output streams.

class myArray -> The class that would wrap the array, int arr[1000], and the methods that are used to accessed it.

int arraySize -> This variable is used to store the size of the array. Though we have defined the array to be of length 1000, but 'arraySize' represents a bound on this length upto which the methods should access the array elements.

myArray()
{
std::cout << "\n\aEnter the size of the array(Upto 1000): ";
std::cin >> arraySize;
std::cout << "\n\aFill the array with " << arraySize;
std::cout << " elements: ";
int i = 0;
for ( i = 0; i < arraySize; i++ )
std::cin >> arr[i];
}
This is the constructor for the myArray class. When the object is created for myArray class, the constructor is called. Since before we perform any operations on the array, we should have an initial array in hand. Thus, the constructor prompts the user to enter an initial arraySize and fill the array with that many elements.

myArray(int argArraySize)
{
arraySize = argArraySize;
std::cout << "\n\aFill the array with " << arraySize;
std::cout << " elements: ";
int i = 0;
for ( i = 0; i < arraySize; i++ )
std::cin >> arr[i];
}

I have made this constructor but never called it. If you wish to make a different kind of object initialisation, you can use this constructor. To use this, you'll have to pass the arraySize to the object when it is created. You can either get the user input and use that user input to act as the argument for the constructor, else you can use a constant int for the purpose.

void insertIntoArray(int insertAt, int insertMe)
{
if ( arraySize < 1000 )
{
arraySize++;
if ( insertAt > arraySize )
{
std::cout << "\nThe array as yet has " << arraySize - 1;
std::cout << " elements.\nThus the new element will be inserted at position " << arraySize;
std::cout << " in the array.\n";
insertAt = arraySize;
}
int i = 0;
for ( i = arraySize + 1; i >= insertAt; i-- )
arr[i] = arr[i - 1];
arr[insertAt - 1] = insertMe;
}
else
std::cout << "\n\n\aALREADY AT LIMITS\n\n\a";
}
This method is used to insert a value into the array. It takes to arguments, first, the position where to enter, second, the value to be entered. The if condition in the beginning of this method is used to do a little bounds checking, to make sure if the array is at limits (1000 in this case), no more insertions are possible. In case the if condition fails, a message telling the user that the array has reached it's limits is issued. In case the if condition stands true, i.e., the array is still in it's limits, we proceed with the insertion. The first thing to do in such case is to increment the value of variable arraySize so that the upper bound on the limit of traversal can be set to correct value. Then we check if the position that user asked is greater than this new value of arraySize. This would mean, insertion outside the bound on the limit. Thus, a message is issued telling the suer the current array size, and thus inserting at the last possible position in the array. To do that, insertAt's value is changed to that of arraySize, in the case explained above only!. Next, a for loop is used to traverse the array upto the position that the user asked. The user asks for a position in the range, [1 , arraySize ], and the computer sees the array in the range [0 , arraySize - 1 ], thus the values of 'i' in the for loop. When the correct position is reached, the value is inserted into the array.

void findPosition(int findMe)
{
int i = 0, flag = 0;
for ( i = 0; i < arraySize; i++)
{
if ( arr[i] == findMe )
{
std::cout << "The number was found at: " << i + 1 << std::endl;
flag = 1;
}
}
if ( flag != 1 )
std::cout<<"The number was not found!" << std::endl;
}
This method is used to find the position of an element in the array, i.e., to implement sequential search on the array. The variable 'i' is the loop counter, and the variable, 'flag' is used to determine success/failure of the search. The for loop searches for the element to be found traversing the array sequentially, and matching the element with every element of the array as the loop moves forward. On each successful match, which is checked by the if condition inside the for loop, the user is signalled by a message denoting the position of the element in the array. To keep the output as per user's perception of array's range, i.e., [1 , arraySize], the 'i+1' is printed and not 'i'. The flag is set to 1 on a successful search. On exiting the loop, the flag value is checked again. If the value is not 1, it indicates that the search was unsuccessful, and hence the user is signalled a failure message.

void deleteFromArray(int deleteMe)
{
int i = 0, j = 0, flag = 0;
for ( i = 0; i < arraySize; i++)
{
if ( arr[i] == deleteMe )
{
arraySize--;
for ( j = i; j < arraySize + 1; j++ )
arr[j] = arr[j + 1];
flag = 1;
i = -1;
}
}
if ( flag != 1 )
std::cout<<"The number was not found!" << std::endl;
}
This method is used to delete an element from the array. If the element has multiple occurrences in the array, this method would delete all the occurrences of that element. We have 'i' and 'j' as the loop counters, and 'flag' to signal success/failure, which is a consequence of success/failure of the search. The outer for loop simply performs a sequential search on the array to find the element that the user requested to delete from the array. If the element is found, the arraySize is decremented since a deletion implies reduction in array's size. Next, the inner for loop, which starts from the position where the search was successful, i.e., the current value of 'i', and goes on to one more than upper bound on the array limit, i.e., arraySize+1 (because we decremented the arraySize already, but we might still need the last element of the array), moves the elements one position left, thereby deleting the element from the array. The flag is set to 1 since it was a success case. Then the value of 'i' is set to -1, since the out loop will increment the value of 'i', and in case we have 2 successive occurrences of the element, we won't be able to remove both without traversing the array again. Why does this happen? Consider we didn't have the statement i=-1. let the element is present at position 3 and 4. When the loop found the element at position 3, it shifted the array elements one position left. Now the loop would increment the counter. The element formerly on 4, is now on 3, and since the counter has moved to 4, we would skip that occurrence! That's why we need the statement, i=-1. It would force the loop to restart (restart from 0 since i=-1, and the loop will increment it to 0) on each successful search-and-delete operation. Since i=-1 is executed only if the search was successful, we don't end up being caught in an infinite loop. Once we exit the outer for loop, the value of flag is checked. If that value is not 1, it denotes failure, and thus the user is signalled the same.

void displayArray()
{
int i = 0;
std::cout << "\n\aCurrently the array is:";
for (i = 0; i < arraySize; i++)
std::cout << " " << arr[i];
}
This method is used to display the current state of the array. It has a for loop that prints the array upto the arraySize bound.

myArray arrayObject; -> The object is instantiated, and thus the constructor is called.

int choice = 0, num, pos; -> 'choice' is used to hold the value of user's choice in the switch menu, 'num' is used to get the user's input of the element to be inserted/deleted/searched. 'pos' is used to get the user input denoting, the position of the element in case of insertion operation.

case 1:
std::cout << "\nEnter the number to be inserted: ";
std::cin >> num;
std::cout << "\nEnter the position where to enter: ";
std::cin >> pos;
arrayObject.insertIntoArray(pos, num);
break;
Case 1, which gets the user input on what element to be inserted and where it is to be inserted. Then the method insertIntoArray is called with the user input as arguments.

case 2:
std::cout << "\nEnter the number to be deleted: ";
std::cin >> num;
arrayObject.deleteFromArray(num);
break;
Case 2, where the user asks to delete a number, 'num', from the array, and the method deleteFromArray is called with the user input as argument.

case 3:
std::cout << "\nEnter the number to be found: ";
std::cin >> num;
arrayObject.findPosition(num);
break;
Case 3, where the user asks to find the position(s) of occurrence(s) of the number, 'num' in the array. The method findPosition is called with the user input as argument.

case 4:
std::cout << "\n\n\aThank You for Using ArrayOps v2.0\n\aMade by Rogue Coder\n\aPress any key to exit.";
std::cin.get();
exit(0);
break;
Case 4, where the user exits the program.

default:
std::cout << "\a\n\nWRONG CHOICE\a\n\n";
break;
Default case, used to handle unspecified cases, that is, wrong choices in the menu.

exit(0); -> This function is used to exit the program with an error code as it's argument. '0' implies normal exit. Other values are used for debugging purposes.

std::cin.get() -> This statement is used to pause our program, until user presses a key. This function is not necessary in your program, I use it to see my outputs at a paused screen. If you use cmd to run your programs, you might not need this. If you use linux/unix you might not need this. Moreover, removing this line of code from this program, doesn't affect the functionality of the program.

Output(s)




Download Source Code


Sunday, June 22, 2014

Sum of Natural Numbers (Recursion) - C Program

Problem Question


Write a recursive function to obtain the running sum of first 25 Natural Numbers.

Explanation of Problem


I have made a more general program that could handle most of the numbers in the integer limits. The user can obtain the desired output by inputting 25 to the program.

Code


#include <stdio.h>

/**@Title: recSumNat.c*
*@Language: ANSI C*
*@Compiler: GNU GCC*
*@IDE: Code::Blocks 13.12*
*@Author: Toxifier*
*@URL: http://letsplaycoding.blogspot.com/*
*@Date: 22-06-2014*
*/

int recSumNat(int a)
{
  if (a < 1)
    return a;
  else if (a == 1)
    return 1;
  else
    return (a + recSumNat(a-1));
}

int main()
{
  int number;
  printf("\n\nEnter a number: ");
  scanf("%d", &number);
  printf("\n\nSum of Natural numbers upto %d: %d\n\n", number, recSumNat(number));
  system("pause");
  return 0;
}


Explanation of Code


#include <stdio.h> -> This is the step which occurs before compilation starts. The compiler calls the C Preprocessor to include the STDIO(Standard Input Output) header file into the program, thus letting the use of the standard input/output functions like printf() and scanf() which come from STDIO.H

int main() -> The entry point of the program where the execution starts. This function has to be named main. As per the ANSI specification, the return type has to be int. If you use the traditional C, you may use void as the return type. Since the return type is specified as int in my program, I have to use a return statement at the end of my code. So I use return 0 since zero returned from a function, by convention, implies a correct execution of the program. The return values are used to debug the program.

printf() -> This is a standard output function used to print something on the screen. We have to pass a string to this function which will be displayed on user's terminal.

scanf() -> This is the scanf() function which waits for the user to enter certain value using his/her keyboard. We store the user input at the location in memory which is pointed to by the variable whose address is passed to this function.

if (a < 1) return a; -> If the user enters an integer which is not a Natural Number, the program would return the number itself, since the program is trying to find the sum of natural numbers upto the number entered by the user, that is, first n natural numbers.

else if (a == 1)
return 1;
-> As soon as the value of the 'a' argument becomes 1, the function returns 1.

else
return (a + recSumNat(a-1));
-> For any natural number other than 1, the function returns the sum of the current value of 'a' with the current call to the function, and the value returned by the function when called with 'a-1'. Thus, we are guaranteed to exit the recursive stack as soon as the value of 'a' reaches 1.

system("pause") -> This statement is used to pause the program, until user presses a key. This function is not necessary in your program, I use it to see my outputs paused. If you use cmd to run your programs, you might not need this. If you use linux/unix you might not need this. Depending on your compiler, this function may or may not work. Moreover, removing this line of code from this program, doesn't affect the functionality of the program.

Output(s)





Download Source Code


Thursday, June 12, 2014

Binary Equivalent of a Number using Recursion - C Program

Problem Question


A positive integer is entered through the keyboard, write a function to find binary equivalent of this number using recursion.

Explanation of Problem


We need to design a recursive function that could find the binary equivalent of a positive integer. It is a simple program. All our function needs to do is print the (number modulus 2) at each iteration, while we keep feeding the next call with number/2.

Code


#include <stdio.h>
/**@Title: BinaryEquivalent Recursive.c*
*@Language: ANSI C*
*@Compiler: GNU GCC*
*@IDE: Code::Block 13.12*
*@Author: Toxifier*
*@URL: http://letsplaycoding.blogspot.com/*
*@Date: 12-06-2014*
*/
void binaryEquiRec(long a)
{
  if (a)
  {
    int num = a % 2;
    binaryEquiRec(a / 2);
    printf("%d", num);
  }
}

int main()
{
  long number;
  printf("\n\nEnter a number: ");
  scanf("%ld", &number);
  printf("\nBinary equivalent of %ld is: ", number);
  binaryEquiRec(number);
  printf("\n\n");
  system("pause");
  return 0;
}


Explanation of Code


#include <stdio.h> -> This is the step which occurs before compilation starts. The compiler calls the C Preprocessor to include the STDIO(Standard Input Output) header file into the program, thus letting the use of the standard input/output functions like printf() and scanf() which come from STDIO.H

int main() -> The entry point of the program where the execution starts. This function has to be named main. As per the ANSI specification, the return type has to be int. If you use the traditional C, you may use void as the return type. Since the return type is specified as int in my program, I have to use a return statement at the end of my code. So I use return 0 since zero returned from a function, by convention, implies a correct execution of the program. The return values are used to debug the program.

printf() -> This is a standard output function used to print something on the screen. We have to pass a string to this function which will be displayed on user's terminal.

scanf() -> This is the scanf() function which waits for the user to enter certain value using his/her keyboard. We store the user input at the location in memory which is pointed to by the variable whose address is passed to this function.

if (a) -> Since in each recursive call, we divide the number fed to the function by 2 (binaryEquiRec(a / 2);), this if condition guarantees that the function would return in case 'a' becomes zero, which would mean 'a / 2 = 0', which is rue iff 'a' is zero. I keep dividing the number by 2 in each call because since we use the statement, int num = a % 2; to set 'num' as 'a % 2', it means we should reject the current 2's multiple from the number to keep on going with our calculation (the current multiple has already contributed).

printf("%d", num); -> This statement is used to print the binary equivalent digit by digit. I have called this after the recursive call to get the number in correct order, else I would get the reverse of the binary equivalent. So what happens is that, as soon as the if condition fails, the last function call returns, that means the MSD of the binary equivalent is returned, which must be published as the leading bit.

system("pause") -> This statement is used to pause the program, until user presses a key. This function is not necessary in your program, I use it to see my outputs paused. If you use cmd to run your programs, you might not need this. If you use linux/unix you might not need this. Depending on your compiler, this function may or may not work. Moreover, removing this line of code from this program, doesn't affect the functionality of the program.

Output(s)




Download Source Code


Tuesday, June 03, 2014

Basic Operations on Array (Traversal, Insertion, Deletion, Search) - Data Structures - C++ Program (Procedural)

Problem Question


Implement the data structure, Array, and write a program to perform basic operations, Traversal, Insertion, Deletion, and Search on it.

Explanation of Problem


In this program, we are required to use array and perform the basic operations listed above on it. Since traversal is nothing but going through all the elements, there is no point performing only traversal since there won't be any output of it. So the loop that displays the whole array in my program is to be considered as traversal of the array. Search is implemented as sequential search for simplicity of the program.

Code


#include <iostream> //Support C++
#include <cstdlib> //For exit()

/**@Title: Array.cpp*
*@Programming Paradigm: Procedural*
*@Language: C++*
*@Compiler: GNU GCC*
*@IDE: Code::Blocks 13.12*
*@Author: Rogue Coder*
*@URL: http://letsplaycoding.blogspot.com/*
*@Date: 03-06-2014*
*/

using namespace std;

int main()
{
  int Arr[100],choice=0,j,del,ins,pos,flag=0,len;
  cout<<"\nWelcome to ArrOps v1.0\nMade by Rogue Coder\n\n\aEnter the size of the array(upto 100): ";
  cin>>len;
  cout<<"\n\aEnter the elements of the array ";
  for(int i = 0; i < len; i++)
    cin>>Arr[i];
  do
  {
    cout<<"\nCurrently, the Array is: ";
    for(int i = 0; i < len; i++)
      cout<<" "<<Arr[i];
    cout<<"\n\nChoices:"
      <<"\n1. Delete an item"
      <<"\n2. Insert an item "
      <<"\n3. Find the position of an item"
      <<"\n4. Exit\n"
      <<"\nYour Choice: ";
    cin>>choice;
    switch(choice)
    {
    case 1:
      cout<<"\n\aEnter the item you wish to delete : ";
      cin>>del;
      for(int i = 0; i < len; i++)
      {
        if(Arr[i] == del)
        {
          len--;
          for(j = i; j < len + 1; j++)
            Arr[j] = Arr[j+1];
          flag = 2;
          i = -1;
        }
      }
      if(flag==2)
        cout<<"\a!!!Entry Deleted!!!\n";
      if(flag!=2)
        cout<<"\a!!!Entry not found!!!\n";
      flag = 0;
      break;

    case 2:
      if (len >= 100)
        cout<<"\n\nALREADY AT LIMITS!!\n\n";
      else
      {
        len++;
        cout<<"\aEnter the position where to insert: ";
        cin>>pos;
        cout<<"\aEnter the item : ";
        cin>>ins;
        for(j = len + 1; j >= pos; j--)
          Arr[j] = Arr[j - 1];
        Arr[pos - 1] = ins;
        cout<<"\n\a!!!New item added!!!\n";
      }
      break;

    case 3:
      cout<<"\aEnter the item to be found : ";
      cin>>ins;
      for(int i = 0; i < len; i++)
      {
        if(Arr[i] == ins)
        {
          cout<<"\aThe item is at: " << i+1 << endl;
          flag = 1;
        }
      }
      if(flag!=1)
        cout<<"\a!!!Value was not found in the array!!!";
      flag = 0;
      break;

    case 4:
      cout<<"\n\aThank you for using ArrOps v1.0\n\aMade by Rogue Coder\nPress any key to exit\a";
      cin.get();
      exit(0);
    default:
      cout << "\n\nWrong Choice\n\n";
      break;
    }
  }
  while(choice!=4);
  cin.get();
  return 0;
}

Explanation of Code


#include <iostream> -> The compiler calls the Preprocessor to include the IOSTREAM(Standard Input / Output Streams Library) header file into the program, thus letting the use of the Standard Input / Output Streams functions like std::cin and std::cout. As per C++11 specification, including <iostream> automatically includes also <ios>, <streambuf>, <istream>, <ostream> and <iosfwd>.

int main() -> The entry point of the program where the execution starts. This function has to be named main. As per the ANSI specification, the return type has to be int. Since the return type is specified as int in my program, I have to use a return statement at the end of my code. So I use return 0 since zero returned from a function, by convention, implies a correct execution of the program. The return values are used to debug the program.

std::cin (extern istream cin) -> Standard Input Stream, and object of class istream. It is generally used with the extraction operator (>>), though we can use member functions like get (cin.get()), read (cin.read()), etc. for the input. The use of extraction operator is much more popular due to the fact that it aids in getting formatted input.

std::cout (extern ostream cout) -> Standard Output Stream, and object of class ostream. It is generally used with the insertion operator (<<), though we can use member functions like write (cout.write()) for the output. The use of insertions operator is much more popular due to the fact that it aids in giving formatted output.

using namespace std; -> In modern IDEs, we have to explicitly write std::cout instead of cout to use the ostream cout object. Namespace std helps in easing off the pain of writing std:: again and again. Though make sure you are not trapped! The classes defined in std should not be redefined by you. So in case you want to define a class 'distance', you can't do so if you have used std namespace. Tough you can define 'Distance' (capital D).

std::endl (ostream& endl (ostream& os)) -> This is a function which is used to insert a newline character and flush the stream. Because this function is a manipulator, it is designed to be used alone with no arguments in conjunction with the insertion (<<) operations on output streams.

int Arr[100],choice=0,j,del,ins,pos,flag=0,len; -> 'Arr' is the array of 100 integers. 'choice' is used for the switch and do-while loop. 'j' is one of the loop counters. 'del' is used to get user input for the number he wishes to delete. 'ins' is used to get the user input for the number he wishes to insert in the array. 'pos' is used to get the input from the user for the position where to insert a number in the array. 'flag' is used to print various messages. 'len' is used to denote the length of the array (upto 100).

for(int i = 0; i < len; i++)
cin>>Arr[i];
-> The user enters the array elements one by one. This loop can be considered an initial traversal operation.

cout<<"\nCurrently, the Array is: ";
for(int i = 0; i < len; i++)
cout<<" "<<Arr[i];
-> This is array traversal operation in my program. This step occurs before the menu is displayed to the user. This display of the array elements can be considered as a help to the user to keep track of the things.

cout<<"\n\aEnter the item you wish to delete : ";
cin>>del;
for(int i = 0; i < len; i++)
{
if(Arr[i] == del)
{
len--;
for(j = i; j < len + 1; j++)
Arr[j] = Arr[j+1];
flag = 2;
i = -1;
}
}
if(flag==2)
cout<<"\a!!!Entry Deleted!!!\n";
if(flag!=2)
cout<<"\a!!!Entry not found!!!\n";
flag = 0;
-> This is the case 1 where the user is asked to enter the element he wants to delete from the array. The user input gets stored in the variable 'del'. Using the for loop, we search for the element in array and if the element is found we delete it. A first, the variable 'len' is decremented so that the effective length of the array (which is traversed in various operations) is decreased. To delete the element, we shift the array entries successive to this found element one position left, thus overwriting the position. The inner for loop achieves this. The flag is set to 2 if the element is found. The line i = -1; in the inner for loop forces the outer loop to run again searching the array from element zero so that all possible matches can be deleted. Consider a case where the array holds, 1 as the first three elements. When the loop first runs, it deletes 1 at Arr[0]. But on second iteration, the 1 at Arr[1] will be shifted to Arr[0], and the outer for loop has already traversed 1 and thus won't be able to delete it. Thus I used i = -1; so that in case the number is found the program is forced to perform the search from element 0 so that none of the occurrences of the number to be deleted are left undeleted. Now if the flag was set to 2, that means the number was found and thus deleted, hence a message number deleted is printed, else Number not found is printed on the screen.

if (len >= 100)
cout<<"\n\nALREADY AT LIMITS!!\n\n";
else
{
len++;
cout<<"\aEnter the position where to insert: ";
cin>>pos;
cout<<"\aEnter the item : ";
cin>>ins;
for(j = len + 1; j >= pos; j--)
Arr[j] = Arr[j - 1];
Arr[pos - 1] = ins;
cout<<"\n\a!!!New item added!!!\n";
}
Here we handle the second case of insertion into the array. At first we check if the number of elements in the array are greater than or equal to 100. Since our Array is designed to handle 100 ints, if the if condition comes out to be true, we print that array is at limits and break from the case. But if that is not the case, we continue with the insertion process. At first the variable 'len' is incremented so that the effective length of the array (which is traversed in various operations) is increased. Then the user is asked to enter number and the position where to inser that number. A for loop is used that startes from the end of the array and goes left till the position where we wish to insert the number. It keeps shifting the entries one unit right in the array. That;s the reason why the loop is started at len + 1 (and not len) and goes till pos (and not pos + 1). Once this is done, the number the user wanted to insert is inserted at Arr[pos - 1] because the array is from 0 to len-1, and the user assumes it to be from 1 to len. "New item added" is printed on screen.

cout<<"\aEnter the item to be found : ";
cin>>ins;
for(int i = 0; i < len; i++)
{
if(Arr[i] == ins)
{
cout<<"\aThe item is at: " << i+1 << endl;
flag = 1;
}
}
if(flag!=1)
cout<<"\a!!!Value was not found in the array!!!";
flag = 0;
Here we habdle the situation of searching an element in the array. The user is asked to enter the number he wants to search. Then the for loop executes a sequential search on the array. Each time the element is found, a message indicating the success and the position of the element is printed on the screen. The 'flag' in such case is set to 1. Out of the loop, we check the value of 'flag' variable, if not 1, implies that the number was not present in the array and thus a message if failure is printed on the user's screen.

exit(0); -> This function is used to exit the program with an error code as it's argument. '0' implies normal exit. Other values are used for debugging purposes.

std::cin.get() -> This statement is used to pause our program, until user presses a key. This function is not necessary in your program, I use it to see my outputs at a paused screen. If you use cmd to run your programs, you might not need this. If you use linux/unix you might not need this. Moreover, removing this line of code from this program, doesn't affect the functionality of the program.

Output(s)




Download Source Code
